Description：

Introducing our latest waterproof and breathable acoustic membrane, designed to offer robust protection without compromising on acoustic performance. Built from high-quality materials, this membrane is ideal for applications requiring reliable waterproofing with superior air permeability and sound transmission properties. Purchase confidently from us, knowing you’re receiving a brand new, authentic product that meets stringent industry standards. For any inquiries or further information, please feel free to reach out, and we will respond promptly.

Technical Specifications

Key Features of the Waterproof Acoustic Membrane

• High Acoustic Performance: With a transmission loss of <2 dB at 3000Hz, this membrane allows clear sound transmission while ensuring waterproofing.
• Superior Air Permeability: Offers excellent air exchange with a permeability rate exceeding 1200 ml/min/cm² at 70 mbar, supporting ventilation needs.
• Exceptional Waterproof Rating: IP67 rating ensures reliable waterproof protection, preventing water ingress while maintaining sound clarity.
• Durability in Extreme Temperatures: The membrane withstands temperatures from -20°C to 100°C, making it suitable for various environments.
• Hydrophobic Material: Constructed from ePTFE, a material known for its hydrophobic properties, providing robust waterproofing.
• Versatile and Flexible: Thin and flexible for easy integration in diverse applications, such as electronic devices, automotive components, and more.

Design and Dimensions

Our GT010 waterproof and breathable membrane is crafted for easy adaptation to various designs, offering compatibility with a range of enclosure sizes and shapes. The precise dimensions ensure reliable performance while maintaining structural integrity across different applications. Specific design customization options may be available upon request.

Installation and Handling Instructions

For optimal installation and performance, please follow these guidelines when handling and installing the GT010 membrane:

1. Temperature Consideration: Ensure that the GT010 membrane and the enclosure are at a temperature above 10°C to facilitate easier application.
2. Handling Precautions:
   • Always use gloves or rounded tweezers to handle the membrane.
   • Avoid direct contact with sharp objects, as this could damage the membrane surface.
3. Preparation of Installation Surface:
   • Make sure the surface is clean, dry, and free from oils, dust, or other contaminants.
   • For best results, install the membrane on a flat, vertical surface to prevent the accumulation of liquid or debris around the edges.
4. Automated Installation:
   • If using an automatic installation machine, follow the machine’s guidelines to ensure correct positioning and application.
5. Manual Installation:
   • Roll the release liner under the membrane until the membrane is fully separated, allowing for easier handling.
   • Avoid lifting or prying the membrane from the release liner with excessive force, as this may cause damage.
6. Installation Assistance Markings:
   • For precision in installation, use alignment markers or embedded guides in the final product design to ensure accurate placement of the membrane.

Applications of the GT010 Membrane

This versatile waterproof and breathable membrane is suitable for numerous applications where both waterproofing and acoustic transmission are essential. Common uses include:

• Electronics and Electrical Equipment: Provides a protective barrier while allowing sound to pass, ideal for speaker grills, microphones, and vents in consumer electronics.
• Automotive Industry: Suitable for automotive components that require waterproofing and airflow, such as sensors and vents.
• Industrial and Medical Devices: Ensures reliable performance and protection in various devices, including ventilation systems and medical enclosures.

With its robust design, exceptional permeability, and waterproof features, the GT010 membrane offers a reliable solution for industries needing both protection and acoustic performance.
